Page 100
Chapter 5: Local Management
5-54
6E128-26, 6E138-25, 6E129-26 and 6E139-25 User’s Guide
Figure 5-20
COM Port Warning Screen
3.
Use the arrow keys to highlight YES. Press ENTER.
4.
If you the port was enabled, proceed to
. If the port was
disabled, use the arrow keys to highlight SAVE at the bottom of the
screen, then press ENTER. When the message “SAVED OK”
displays, the edits are saved.
NOTE
If the 6C105 chassis has been configured with a valid IP
address this screen will not appear. When the chassis is
assigned a valid IP address all the interface modules installed
share this same address.
!
CAUTION
Exiting without saving causes the message “NOT SAVED --
PRESS SAVE TO KEEP CHANGES” to appear. Exiting without
saving causes all edits to be lost.
WARNING
174252
THE COM PORT HAS BEEN RECONFIGURED AND THERE IS NO IP
ADDRESS SET FOR THIS DEVICE. YOU WILL NO LONGER BE ABLE
TO MANAGE THIS BOARD. DO YOU STILL WISH TO RECONFIGURE
THIS COM PORT?
YES
NO
