Note: The commons (COM) terminals are connected together
Number 4
type voltage or current
(selectable by dip-switch),
optoinsulated
Jumper inserted Current
Current range 0 - 20 mA
Current output accuracy ±1 mA
Current output resolution 0.05 mA
Maximum load of current output 50 - 250Ω
Current output settling time 1 sec
Jumper not inserted Voltage
Voltage range 0,5 - 10 V
Voltage output accuracy ±200 mV (without load)
Voltage output resolution 10 mV
Maximum load of voltage output 200Ω
Voltage output settling time 1 sec
Analog outputs
Note:
1) not protected output against permanent short circuit
2) ((Zl/(Zo+Zl) use load with impedance Zl>1K
Ω
Number 8
type electromechanical relays
With NO contacts 6
With SPDT contacts 2
Contact ratings 2000VA 250Vac, 8A
cos
θ
=1
6(4) accordino to
EN60730-1
Contact life cycle > 100.000
Digital outputs
Note:
1)The commons (COM) terminals are not connected together
2) Primary insulation is guaranteed between the relays
Number
1
type CAN V2.0B
no optoinsulated
Physical layer 2 wires + common wire
(ISO 11898)
Baud rate (max. length = 10 m) 20K
Baud rate (max. length = 5 m) 50K
Baud rate (max. length = 2 m) 125K
Baud rate (max. length = 1 m) 500K
Internal CAN
communication bus
Connector Disconnectable screw
terminals
