ssg <= "0111111" when dig = "0000" else
"0000110" when dig = "0001" else
"1011011" when dig = "0010" else
"1001111" when dig = "0011" else
"1100110" when dig = "0100" else
"1101101" when dig = "0101" else
"1111101" when dig = "0110" else
"0000111" when dig = "0111" else
"1111111" when dig = "1000" else
"1101111" when dig = "1001" else
"1110111" when dig = "1010" else
"1111100" when dig = "1011" else
"0111001" when dig = "1100" else
"1011110" when dig = "1101" else
"1111001" when dig = "1110" else
"1110001" when dig = "1111" else
"0000000";
-- Digit multiplexor. The anode for each digit in enabled
-- in succession, and the appropriate cathode data is muxed onto
-- the cathode lines while the corresponding anode is driven.
an <= "1110" when cntDig = "00" else
"1101" when cntDig = "01" else
"1011" when cntDig = "10" else
"0111" when cntDig = "11" else
"1111";
dig <= regSsg(15 downto 12) when cntDig = "00" else
regSsg(11 downto 8) when cntDig = "01" else
regSsg( 7 downto 4) when cntDig = "10" else
regSsg( 3 downto 0);
-- Map the internal signals to the pins on the CPLD.
rgbSsgAn <= an;
rgbSsgCa <= '1' & (not ssg);
kclk <= kcin;
kdat <= kdin;
end Behavioral;
