DIO5 Expansion Connector Pinout
P1 Signal Dir P2 Signal Dir
1 TDO 1 nc
2 TDI 2 nc
3 TMS 3 nc
4 TCK 4 nc
5 nc 5 nc
6 JTSEL (VCC33) 6 nc
7 nc 7 nc
8 nc 8 nc
9 nc 9 nc
10 nc 10 IO-06 open
11 SW1 out 11 CLK2
12 nc 12
IO-05 open
13 SW3 out 13 IO-04 open
14 SW2 out 14 IO-03 open
15 SW5 out 15 IO-02 open
16 SW4 out 16 IO-01 open
17 SW7 out 17 nc
18 SW6 out 18 nc
19 LCLK in 19 KDAT out
20 SW8 out 20 KCLK out
21 DB7 bidi 21 HS in
22 CS in 22 LCLK in
23 DB6 bidi 23 BLU in
24 OE in 24 VS in
25 DB5 bidi 25 RED in
26 WE in 26 GRN in
27 DB4 bidi 27
BOUTE out
28 ADR5 in 28 BOUTF out
29 DB3 bidi 29 BOUTC out
30 ADR4 in 30 BOUTD out
31 DB2 bidi 31 BOUTA out
32 ADR3 in 32 BOUTB out
33 DB1 bidi 33 BCOD2 out
34 ADR2 in 34 BCOD3 out
35 DB0 bidi 35 BCOD0 out
36 ADR1 in 36 BCOD1 out
37 VCC33 37 VCC33
38 ADR0 in 38 LCDEN in
39
GND 39 GND
40 VU 40 VU
