rgbSwt : in std_logic_vector(7 downto 0);
encBtn : out std_logic_vector(3 downto 0);
rgbBtnOt : out std_logic_vector(5 downto 0);
rgbLed : out std_logic_vector(15 downto 0);
rgbSsgAn : out std_logic_vector(3 downto 0);
rgbSsgCa : out std_logic_vector(7 downto 0);
kclk : out std_logic;
kdat : out std_logic;
kcin : in std_logic;
kdin : in std_logic);
end DlabDio5;
architecture Behavioral of DlabDio5 is
------------------------------------------------------------------------
-- Component Declarations
------------------------------------------------------------------------
------------------------------------------------------------------------
-- Constant and Signal Declarations
------------------------------------------------------------------------
-- Internal registers for output devices
signal regLed : std_logic_vector(15 downto 0);
signal regSsg : std_logic_vector(15 downto 0);
signal regBtn : std_logic_vector(15 downto 0);
signal rgbSyncBtn : std_logic_vector(15 downto 0);
-- Other needed signals
signal busDout : std_logic_vector(7 downto 0);
signal cntDig : std_logic_vector(1 downto 0) := "00";
signal ssg : std_logic_vector(6 downto 0);
signal dig : std_logic_vector(3 downto 0);
signal an : std_logic_vector(3 downto 0);
----------------------------------------------------------------------------
-- Module Implementation
----------------------------------------------------------------------------
begin
------------------------------------------------------------------------
-- Bus drive control logic. Data bus is driven only when oe and cs are valid.
------------------------------------------------------------------------
db <= busDout when (oe = '0' and cs = '0') else "ZZZZZZZZ";
-- Output mux to place selected data on bus
busDout <= rgbSyncBtn(7 downto 0) when adr = "000000" else
rgbSyncBtn(15 downto 8) when adr = "000001" else
rgbSwt when adr = "000010" else
rgbLcd;
------------------------------------------------------------------------
-- Registers for On-Board Output Devices
(LEDs and Sseg display)
------------------------------------------------------------------------
-- The WE signal is driven from a global clock buffer.
process (we)
begin
if (we'event and we = '1') then
if (adr = "000000" and cs = '0') then regLed( 7 downto 0) <= db; end if;
if (adr = "000001" and cs = '0') then regLed(15 downto 8) <= db; end if;
if (adr = "000010" and cs = '0') then regSsg( 7 downto 0) <= db; end if;
