POWER FAILURE PROCESS
If power failure occurs, all sales totals stored in the memories are auto­
matically protected by the battery installed in the ECR. The battery is
rechargeable and it is recharged when AC power returns. As the power returns,
the register revives to continue the work. However, please note the following
phenomena to occur on the register when the power is regained:
1. The printer will work to print the entered data without failure after
the power recovery, if any data was being printed. However, one extra
line may be fed on the power recovery depending on the power recovery
timing.
The display will indicate, on the power recovery, the content that
was displayed before the power failure. However, if only any numeric
[T] , ILC OPEN keys or non-motor ized keys (such as 1RTN ITX/M
PR OP e F] ) was depressed without any motorized key (such as I DEPTi
keys) depressed thereafter at the starting of a sale registration,
and then the power failed; the entered numeric value or non-motorized
key wilt have disappeared by the time of power recovery and the display
will indicate "0.00". Therefore, after the power recovery, do the
registering operation again from the very first key-in operation.
SPECIFICATIONS
Size ........................... 460mm(width) x 400mm(depth) x 375mm(height)
---With SP Drawer
Weight ......................... 19.0 Kg (With SP Drawer)
Power Required ................. AC 117V 60Hz
Power Consumed .......... . IIW when non-operating
35W (0.4A) when operating
Size of Receipt and Journal Tape
......... 38mm(width) x 70mm(diameter)
‘ Ambient Temperature ........... O^C ~ 40°C, 107c. ~ 90% Relative Humidity
- 8 9 -
