Fig. 63 — 42SG,SH,SJ,VA,VB,VC,VE,VF 2-Pipe Cooling with Total Electric Heat —
Unit-Mounted Debonair
®
Thermostat (24-v) and Duct Sensor
a42-4072
NOTE: Units may have 2 or 4
elements. Elements wired in
parallel.
Fig. 64 — 42C,S,V (except VG), and 42D (600-1000 cfm) 2-Pipe Cooling with Total Electric Heat —
Remote/Wall-Mounted Debonair
®
Thermostat (24-v) and Dual Power Source
