Page 12
12
UNIT
SIZE
NOM
AIRFLOW
(Cfm)
DIMENSIONS (in.)
QTY/UNIT
BOTTOM RETURN
FILTER SIZE, (in.)
A
B
C
D
E
F
Blower
Motor
02
200
35
16
12
3
/
4
37
32
6
1
1
10 x 28
03
300
35
20
8
3
/
4
37
32
6
1
1
10 x 28
04
400
41
26
8
3
/
4
43
38
6
2
1
10 x 33
06
600
53
31
15
3
/
4
55
50
7
2
1
10 x 45
08
800
53
38
8
3
/
4
55
50
7
2
1
10 x 45
10
1000
75
52
16
3
/
4
77
72
7
4
2
10 x 62
12
1200
75
60
8
3
/
4
77
72
7
4
2
10 x 62
NOTES:
1. Right hand unit shown; left hand unit opposite.
2. Internal factory valve package and drains may not align with
cabinet knockouts.
3. Dimensions shown in inches (mm). All dimensions are ±
1
/
4
in.
4. Bottom panel is Arctic White polyester powder coat paint.
A42-4149
Fig. 9 — 42CK Horizontal Cabinet Unit with Telescopic Access Panel,
Front Supply, and Bottom Return Dimensions
