Table 1 — Physical Data — 42C Series Units
*Calculate operating weight of unit: shipping weight + coil water weight x
number of coil rows.
†42CF applies to sizes 04 to 10.
**Filter size for return-air grille location.
††Filter size if located in return-air plenum.
***With electric heater and bottom return, the 42CF unit filter width increases
from 12
3
/
4
to 16
3
/
4
.
Table 2 — Physical Data — 42V Series Units
*Calculate operating weight of unit: shipping weight + coil water weight x
number of coil rows.
†Available in sizes 02-06.
UNIT SIZE 42C
02
03
04
06
08
10
12
NOMINAL AIRFLOW (cfm)
200
300
400
600
800
1000
1200
SHIPPING WEIGHT (lb)*
42CA
36
39
49
59
64
95
107
42CE
55
60
70
82
95
135
154
42CF
—
—
84
97
110
163
—
42CG
98
118
126
168
176
215
245
42CK
115
120
135
150
155
227
241
COIL WATER WEIGHT
(Approx lb per row of coil)
42CA, CE, CG, CK
0.7
0.8
1.0
1.4
1.7
2.3
2.7
42CF
—
—
1.02
1.42
1.71
2.32
—
COILS
FPI
10 fins/inch
Coil Face Area (sq ft)†
0.8
1.1
1.4
1.9
2.3
3.2
3.7
MOTOR (qty)
42C Series
1
1
1
1
1
2
2
BLOWER (qty)
42CA, CE, CG, CK
1
1
2
2
2
4
4
42CF
—
—
2
2
2
4
—
FILTERS
Nominal Size (in.) (1-in. thick)
42CA**
10 x 24
10 x 28
10 x 32
10 x 42
10 x 42
10 x 54
10 x 64
42CE††
10 x 18
10 x 22
10 x 28
10 x 33
10 x 40
10 x 54
10 x 62
42CF††***
—
—
12
3
/
4
x 28
12
3
/
4
x 33
12
3
/
4
x 40
12
3
/
4
x 54
—
42CG
Bottom Return
10 x 23
1
/
2
10 x 28
10 x 32
1
/
2
10 x 37
10 x 41
10 x 54
1
/
2
10 x 63
Rear Return
8 x 23
1
/
2
8 x 28
8 x 32
1
/
2
8 x 37
8 x 41
8 x 54
1
/
2
8 x 63
42CK
Bottom Return
10 x 28
10 x 28
10 x 33
10 x 45
10 x 45
10 x 62
10 x 62
Rear Return
7 x 21
7 x 21
7 x 27
7 x 38
7 x 38
7 x 52
7 x 52
Rear Return with Duct Collar
6 x 18
3
/
4
6 x 18
3
/
4
6 x 24
3
/
4
6 x 35
3
/
4
6 x 35
3
/
4
6 x 49
3
/
4
6
x
49
3
/
4
Qty
1
1
1
1
1
1
1
SUPPLY DUCT COLLAR
1-in.
PIPING CONNECTIONS (Sweat) (in.)
Coil Outlet and Inlet
5
/
8
OD
Drain Connection
7
/
8
OD
Tell-Tale Drain
5
/
8
OD
UNIT SIZE 42V
01
02
03
04
06
08
10
12
NOMINAL AIRFLOW (cfm)
150
200
300
400
600
800
1000
1200
SHIPPING WEIGHT (lb)*
42VA
—
65
80
90
112
115
140
170
42VB
—
89
95
116
134
137
169
192
42VC
—
50
60
72
110
—
—
—
42VE
—
72
100
108
154
—
—
—
42VF
—
92
98
122
141
144
178
205
42VG
40
—
74
—
—
—
—
—
COIL WATER WEIGHT
(Approx lb per row of coil)
42VA, VB, VC†, VF
—
0.7
0.8
1.0
1.4
1.7
2.3
2.7
42VE
—
0.9
1.2
1.6
2.3
—
—
—
42VG
0.4
—
1.0
—
—
—
—
—
COILS
FPI
12 fins/inch
Coil Face Area (sq ft)
0.8
0.8
1.1
1.4
1.9
2.3
3.2
3.7
MOTOR (qty)
42VA, VB, VF
—
1
1
1
1
1
2
2
42VC, VE
—
1
1
1
2
—
—
—
42VG
1
—
2
—
—
—
—
—
BLOWER (qty)
42VA, VB, VF
—
1
1
2
2
2
4
4
42VC, VE
—
2
2
2
4
—
—
—
42VG
1
—
2
—
—
—
—
—
FILTERS
Nominal Size (in.) (1-in. thick)
42VA, VB, VF
—
7
3
/
4
x 21
3
/
4
7
3
/
4
x 25
3
/
4
7
3
/
4
x 31
3
/
4
7
3
/
4
x 41
3
/
4
7
3
/
4
x 43
3
/
4
7
3
/
4
x 57
3
/
4
7
3
/
4
x 65
3
/
4
42VC, VE
—
7 x 21
3
/
4
7 x 26
3
/
4
7 x 34
3
/
4
7 x 48
3
/
4
—
—
—
42VG
10 x 14
1
/
2
—
10 x 28
—
—
—
—
—
Qty
1
1
1
1
1
1
1
1
SUPPLY DUCT COLLAR
1-in.
PIPING CONNECTIONS (Sweat) (in.)
Coil Outlet and Inlet
5
/
8
OD
Drain Connection
3
/
4
MPT
