LEGEND
1 — Optional Unit Mounted Control Box
2 — Wall Mounting Holes (4),
3
/
4
-in. Diameter
3 — Drain,
3
/
4
-in. MPT
4 — Drain Pan, Auxiliary, Shipped Loose
5 — Supply Conn,
5
/
8
-in. OD
6 — Return Conn,
5
/
8
-in. OD
7 — Filter
8 — Air Vent,
1
/
8
-in. MPT
9 — Discharge Opening
10 — Flexible Conduit
11 — Front Access Panel
*Unit weights are based on dry coils and minimum rows. Weights exclude packaging, valves, and other components.
UNIT
SIZE
NOM
AIRFLOW
(Cfm)
DIMENSIONS (in.)
QTY/UNIT
FACE
AREA
(sq ft)
UNIT
WEIGHT*
(lb)
A
B
C
D
Blower
Motor
02
200
25
22
23
1
/
2
16
1
1
0.83
65
03
300
29
26
27
1
/
2
20
1
1
1.08
80
04
400
35
32
33
1
/
2
26
2
1
1.35
90
06
600
45
42
43
1
/
2
36
2
1
1.88
112
08
800
47
44
45
1
/
2
38
2
1
2.31
115
10
1000
61
58
59
1
/
2
52
4
2
3.16
140
12
1200
69
66
67
1
/
2
60
4
2
3.65
170
NOTES:
1. Right hand unit shown; left hand unit opposite. Coil connection locations
are ±
5
/
8
-in.
2. Unit sizes 02 and 03 have one motor, one blower; sizes 04 through 08
have one motor, 2 blowers; sizes 10 and 12 have 2 motors, 4 blowers.
3. Standard 3-row coil shown.
4. Optional unit-mounted switch box and controls, when specified, are
installed on opposite side from cooling connections.
5. Not shown: 3-speed fan switch; wall plate,
1
/
2
-in. fiberglass insulation on
inside of casing, closed cell foam on main drain pan.
6. Units have galvanized finish.
7. For optional coil connections, view 42VA-203-1 using the Fan Coil
Builder.
8. Dimensions shown in inches (mm).
A42-4109
Fig. 15 — 42VA Furred-In Vertical Unit Dimensions
