Carrier 42V User Manual
Page 19
19
LEGEND
1 — Standard Stamped Supply Grille
2 — Access Door, Fan Switch
3 — Supply Conn,
5
/
8
-in. OD
4 — Return Conn,
5
/
8
-in. OD
5 — Drain,
3
/
4
-in. MPT
6 — Filter
7 — Air Vent,
1
/
8
-in. MPT
8 — Front Panel Fastener
9 — Drain Pan, Auxiliary, Shipped Loose
10 — Wall Mounting Holes (4),
3
/
4
-in. Diameter
11 — Flexible Conduit
12 — Fan Switch, 3-speed
13 — Front Access Panel
NOTES:
1. Right hand unit shown; left hand unit opposite. Coil connection
locations are ±
5
/
8
-in.
2. Unit sizes 02 and 03 have one motor, one blower; sizes 04 through
08 have one motor, 2 blowers; sizes 10 and 12 have 2 motors,
4 blowers.
3. Standard 3-row coil shown.
4. Cabinet has an Arctic White baked finish.
5. Stamped supply grille standard. Optional single or double deflec-
tion grilles available.
6. Not shown:
1
/
2
-in. fiberglass insulation on inside of casing, closed
cell foam on main drain pan.
7. For optional coil connections, view 42VA-203-1 using the Fan Coil
Builder.
8. Dimensions shown in inches (mm).
*Unit weights are based on dry coils and minimum rows. Weights exclude packaging, valves, and other components.
UNIT
SIZE
NOM
AIRFLOW
(Cfm)
DIMENSIONS (in.)
QTY/UNIT
FACE
AREA
(sq ft)
UNIT
WEIGHT*
(lb)
A
B
C
D
E
Blower
Motor
02
200
41
22
23
1
/
2
17
1
/
4
3
5
/
8
1
1
0.83
89
03
300
45
26
27
1
/
2
21
1
/
2
3
1
/
2
1
1
1.08
95
04
400
51
32
33
1
/
2
26
4
1
/
4
2
1
1.35
116
06
600
61
42
43
1
/
2
39
2
3
/
4
2
1
1.88
134
08
800
63
44
45
1
/
2
39
3
3
/
4
2
1
2.31
137
10
1000
77
58
59
1
/
2
52
4
1
/
4
4
2
3.16
169
12
1200
85
66
67
1
/
2
61
3
3
/
4
4
2
3.65
192
A42-4110
Fig. 16 — 42VB Vertical Cabinet Unit Dimensions
