Table 3 — Physical Data — 42D Series Units
*Calculate Operating Weight of unit: Shipping Weight + Coil Water Weight x Number of Coil Rows.
Table 4 — Physical Data — 42S Series Units
*Calculate Operating Weight of Unit: Shipping Weight + Coil Water Weight x Number of Coil Rows.
†42SJ units require two filters.
PRE-INSTALLATION
Unpack and Inspect Units —
Remove shipping wraps
from all units. Check the shipment against shipping order.
Make sure that furnished only items, such as thermostat,
grilles, etc., are accounted for, whether packaged separately or
shipped at a later date. If shipment is damaged or incomplete,
file claim with transportation company and advise Carrier im-
mediately.
Protect Units from Damage —
The equipment must
always be properly supported. Temporary supports used during
installation or service must be adequate to hold the equipment
securely. Equipment should always be stored in the proper ori-
entation as marked on the carton. To maintain warranty, protect
units against adverse weather, theft, vandalism, and debris on
jobsite. Equipment covered in this manual is not suitable for
outdoor installations. Do not allow foreign material to fall into
drain pan. Prevent dust and debris from being deposited on mo-
tor and fan wheels. Manufacturer's warranty is void if foreign
material is allowed to be deposited on the motor or blower
wheels of any unit.
Prepare Jobsite for Unit Installation —
To save
time and to reduce the possibility of costly errors, set up a com-
plete sample installation in a typical room at jobsite. Check all
critical dimensions such as pipe, wire, and duct connection
requirements. Refer to job drawings and product dimension
drawings as required (see Fig. 1-36). Instruct all trades in their
part of the installation.
Identify and Prepare Units —
Be sure power require-
ments match available power source. Refer to unit nameplate
and wiring diagram.
1. Check all tags on unit to determine if shipping screws are
to be removed. Remove screws as directed.
2. Rotate the fan wheel by hand to ensure that the fan is
unrestricted and can rotate freely. Check for shipping
damage and fan obstructions.
UNIT SIZE 42D
06
08
10
12
14
16
18
20
NOMINAL AIRFLOW (cfm)
600
800
1000
1200
1400
1600
1800
2000
SHIPPING WEIGHT (lb)*
42DA
64
79
93
110
119
129
137
155
42DC
94
107
150
169
174
178
195
220
42DD
150
163
176
195
220
235
240
247
42DE
135
155
165
184
199
215
232
243
42DF
157
167
177
199
215
229
249
258
COIL WATER WEIGHT
(Approx lb per row of coil)
1.3
1.6
1.9
2.3
2.7
3.0
3.4
3.7
COILS
FPI
10 fins/inch
Coil Face Area (sq ft)
1.6
2.1
2.5
3.0
3.5
4.1
4.6
5.0
MOTOR (qty)
1
1
1
2
2
2
2
2
BLOWER (qty)
1
1
1
2
2
2
2
2
FILTERS
Nominal Size (in.) (1-in. thick)
42DA
NA
42DC
14 x 21
14 x 26
14 x 30
14 x 35
14 x 40
14 x 45
14 x 50
14 x 54
42DD
(Front Return)
12
3
/
4
x 21
12
3
/
4
x 26
12
3
/
4
x 30
12
3
/
4
x 35
12
3
/
4
x 40
12
3
/
4
x 45
12
3
/
4
x 50
12
3
/
4
x 54
(Bottom Return)
12
3
/
4
x 21
12
3
/
4
x 25
12
3
/
4
x 29
12
3
/
4
x 34
12
3
/
4
x 39
12
3
/
4
x 44
12
3
/
4
x 49
12
3
/
4
x 53
42DE
14 x 14
3
/
4
14 x 19
3
/
4
14 x 23
3
/
4
14 x 28
3
/
4
14 x 33
3
/
4
14 x 38
3
/
4
14 x 43
3
/
4
14 x 47
3
/
4
42DF
14 x 14
14 x 20
14 x 24
14 x 28
14 x 34
14 x 38
14 x 44
14 x 48
Qty
1
SUPPLY DUCT COLLAR
1-in.
PIPING CONNECTIONS
(Sweat - 4-Row)
Inlet (in. OD)
5
/
8
7
/
8
1
1
/
8
Outlet (in. OD)
5
/
8
7
/
8
1
1
/
8
UNIT SIZE 42S
03
04
06
08
10
12
NOMINAL AIRFLOW (cfm)
300
400
600
800
1000
1200
SHIPPING WEIGHT (lb)*
42SG,SU
180
225
240
260
280
305
42SH
202
247
262
286
311
336
42SJ
360
450
480
520
560
610
COIL WATER WEIGHT
(Approx lb per row of coil)
1.6
1.6
2.3
2.3
3.1
3.1
COILS
FPI
14 fins/inch
MOTOR (qty)
42SG,SH,SU
1
1
1
1
1
1
42SJ
2
2
2
2
2
2
BLOWER (qty)
42SG,SH,SU
1
1
1
1
1
1
42SJ
2
2
2
2
2
2
FILTERS
Nominal Size (in.) (1-in. thick)
12
1
/
2
x 24
1
/
4
16
1
/
4
x 26
3
/
4
20
1
/
2
x 29
1
/
4
Qty
1†
PIPING CONNECTIONS
Inlet (in. OD)
1
/
2
