Carrier 42V User Manual
Page 39
39
Fig. 36 — Return-Air Wall Panels for Furred-In Units — Panels with Frame
PANEL AND FRAME DIMENSIONS (in.)
NOTE: Dimensions in inches.
PANEL NO.
UNIT SIZE
A
4
03, 04
15.1
06, 08
19.1
10, 12
23.1
5
03, 04
15.1
06, 08
19.1
10, 12
23.1
9
03, 04
15.1
06, 08
19.1
10, 12
23.1
PANEL NO. 4
54.7
A
A42-4168
PANEL NO. 5
60.4
A
A42-4170
PANEL NO. 9
51.7
A
A42-4161
