Page 23
23
*Unit weights are based on dry coils and minimum rows. Weights exclude packaging, valves, and other components.
UNIT SIZE
NOM
AIRFLOW
(Cfm)
DIMENSIONS (in.)
QTY/UNIT
FACE AREA
(sq ft)
UNIT
WEIGHT*
(lb)
A
B
D
C
Blower
Motor
02
200
41
22
3
3
/
4
17
2
1
1.18
72
03
300
46
27
4
21
1
/
2
2
1
1.53
100
04
400
54
35
3
5
/
8
30
1
/
4
2
1
2.08
108
06
600
68
49
4
1
/
16
43
3
/
8
4
2
3.06
154
LEGEND
1 — Fan Switch, 3-Speed, behind Access Door
2 — Front Panel Fastener
3 — Stamped Supply Grille
4 — Supply Conn,
5
/
8
-in. OD
5 — Return Conn,
5
/
8
-in. OD
6 — Stamped Return Grille
7 — Filter
8 — Air Vent,
1
/
8
-in. MPT
9 — Optional Valve Package (inside cabinet)
10 — Drain Pan, Auxiliary, with
3
/
4
-in. MPT
Drain Connection
11 — Return Air Grille
NOTES:
1. Right hand unit shown; left hand unit opposite. Coil connection
locations are ±
5
/
8
-in.
2. Unit sizes 02 through 04 have one motor, 2 blowers; size 06 has
2 motors, 4 blowers.
3. Cabinet has an Arctic White baked finish.
4. Height increases by 2 in. with electric heat.
5. Standard 2-row coil shown.
6. Not shown:
1
/
2
-in. fiberglass insulation on inside of casing,
closed cell foam on main drain pan.
7. For optional coil connections, view 42VC-203-1 using the Fan
Coil Builder.
8. Valve package is factory-installed inside the cabinet when
ordered with the unit (based on component size).
9. Dimensions shown in inches (mm).
A42-4114
14-3/8
(368)
Fig. 20 — 42VE Cabinet Lowboy Unit Dimensions
