Carrier 42V User Manual
Page 15
15
NOTES:
1. Right hand unit shown; left hand unit opposite.
2. Internal factory valve package and drains may not align with
cabinet knockouts.
3. Dimensions shown in inches (mm). All dimensions are ±
1
/
4
in.
4. Bottom panel is Arctic White polyester powder coat paint.
UNIT
SIZE
NOM
AIRFLOW
(Cfm)
DIMENSIONS (in.)
QTY/UNIT
REAR RETURN
FILTER SIZE, (in.)
A
B
C
D
E
F
Blower
Motor
02
200
35
16
12
3
/
4
37
32
6
1
1
7 x 21
03
300
35
20
8
3
/
4
37
32
6
1
1
7 x 21
04
400
41
26
8
3
/
4
43
38
6
2
1
7 x 27
06
600
43
31
15
3
/
4
55
50
7
2
1
7 x 38
08
800
43
38
8
3
/
4
55
50
7
2
1
7 x 38
10
1000
75
52
16
3
/
4
77
72
7
4
2
7 x 52
12
1200
75
60
8
3
/
4
77
72
7
4
2
7 x 52
a42-4152
Fig. 12 — 42CK Horizontal Cabinet Unit with Telescopic Access Panel,
Front Supply, Rear Return, and Heater Dimensions
