Audio Adjustments
3 C Section
m
• A CUSTOM2 curve can be created com­
mon to all sources.
• If you make adjustments when the
CUSTOM2 curve Is selected, the
CUSTOM2 curve Is updated.
• When FLAT is selected no supplement or
correction is made to the sound. This is
useful to check the effect of the equalizer
curves by s\A/itching alternatively between
FLAT and a set equalizer curve.
• Press EQ to select the equalizer.
Press EQ repeatedly to switch between the fol­
lowing equalizers:
SUPER BASS—POWERFUL—NATURAL-
VOCAL—CUSTOM1—CUSTOM2—FLAT
Adjusting equalizer curves
You can adjust the currently selected equalizer
curve setting as desired. Adjusted equalizer
curve settings are memorized in
CUSTOM1 or
CUSTOM2.
1 Press OPEN to open the front panel.
2 Press AUDIO to select EQ.
Press AUDIO until EQ appears in the display.
3 Press or ► to select the equalizer
band to adjust.
Each press of ◄ or ► selects equalizer bands
in the following order:
EQ Low (low)— EQ Mid (mid)— EQ High
(high)
4 Press A or T to adjust the level of the
equalizer band.
Each press of A or T increases or decreases
the level of the equalization band.
■ h 6 --6 is displayed as the level is increased
or decreased.
■ You can then select another band and adjust
the level.
Note
m
Í
1
1
1
Level (dB)
jO=2N 0=2W
Center frequency^! —>-
Frequency (Hz)
CO
If you make adjustments when a curve other than 3
CUSTOM2 is selected, CUSTOM1 curve is up-
dated.
Fine adjusting equalizer curve
You can adjust the center frequency and the 0
factor (curve characteristics) of each currently
selected curve band (EQ Low/EQ Mid/
EQ High).
1 Press OPEN to open the front panel.
2 Press AUDIO and hold until frequency
and the Q factor (e.g., F 80 Q 1W) appears
in the display.
3 Press AUDIO to select the desired band
for adjustment.
Press AUDIO repeatedly to switch between
the following bands:
Low—Mid—High
4 Press -4 or ► to select the desired fre­
quency.
Press ◄ or ► until the desired frequency ap­
pears in the display.
Low: 40—80—100—160 (Hz)
Mid: 200—500—Ik—2k (Hz)
High: 3.15k—8k—10k—12.5k (Hz)
5 Press A or V to select the desired Q fac­
tor.
Press A or T until the desired 0 factor ap­
pears in the display.
En
( 3 5 )
