2
1.2 Conversion Kit Contents
KC1000 Low NOx Conversion Kit, Part No. 124918-( ) is available in four configurations, designated -
1, -2, -3 and -4. The -1 and -2 Kits apply to newer KC1000 Water Heaters and Boilers respectively,
equipped with Siemens Safety Shutoff Valves (SSOVs) and C-More Control Systems. The -3 and -4
Kits apply to older KC1000 Water Heaters and Boilers respectively, equipped with Honeywell SSOVs.
Older KC1000 units may also be equipped with Modular or Digital Control Systems, instead of the C-
More Control Systems used on current KC1000 units. The “Kit Dash Number” column in the following
Table indicates which parts are included in each Kit. As this Table shows, only minor differences exist
between the contents of the four Kit configurations.
Conversion Kit, Part No. 124918-( ) Contents
Item No. Part No.
Kit Dash
Number Description
1 201258 All Low NOx Burner Assembly
2 124715 All 5/16-18 x 1-3/4” Long Studs (Qty=6)
3 124867 -1, -2 Only Staged Ignition Assembly
4 124983 -3, -4 Only Staged Ignition Assembly
5 124991 All Low NOx Air/Fuel Valve Gas Plate
Assembly
6 161625 All Low NOx Air/Fuel Valve Butterfly
7 124803 All Low NOx Gas Regulator Plated Spring
8 124870 All Solenoid Valve Harness
9 124839 All Low NOx Combustion Chamber Liner
10 124570 All Low NOx Igniter Assembly
11 124837 All Low NOx Flame Rod Assembly
12 124919 All Low NOx Conversion Labels Sheet
13 124797 -1, -3 Only Low NOx Heater Specs. Label
14 124798 -2, -4 Only Low NOx Boiler Specs. Label
15 GF-111LN
or
GF-109LN
-1 Only
or
-2 Only
Low NOx Heater O & M Manual
or
Low NOx Boiler O & M Manual
