Benchmark 6000 Boiler Installation, Operation & Maintenance Manual
APPENDIX G – PART LIST DRAWINGS
OMM-0086_0D
AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913
Page 183 of 210
GF-133
Ph.: 800-526-0288
03/20/14
BMK 6000, FM Gas Train BOM (BOM-22172-1_0C)
Item
Qty
P/N
Description
1
1
123542
FLANGE 2" 125# 2"NPT
2
1
123547
NIPPLE 2" NPT TBE X 2.00 LG
3
1
9-9
REDUCING TEE: 2" X 1/2" X 2" NPT B/I
4
1
94027-32
NIPPLE 2" NPT X 8.00 LG
5
1
123540
VALVE: BALL 2" FULL PORT
6
1
94027-36
NIPPLE 2" NPT TBE X 9.00 LG
7
2
2-4
ELBOW: 90°: 2" NPT
8
1
94027-8
NIPPLE: 2" NPT TBE X 2.00 LG
9
2
95030
FLANGE: SSOV 2" NPT
10
1
124142
VALVE: SSOV: DOUBLE BODY: 2" NPT
11
1
94027-24
NIPPLE 2" NPT TBE X 6.00 LG
12
1
94027-240
NIPPLE: 2" NPT TBE X 60.00 LG
13
1
24383
SKP 25.011U1 W/ 15-120 SET PT
14
1
69171
ACTUATOR: SSOV W/O P.O.C. SW. & AUX SW.
15
2
123533
NIPPLE: CLOSE 1/8"
16
2
93445
COUPLING: REDUCING 1/4 x 1/8 NPT: BLK MI
17
5
93035
ELBOW: STREET 1/4" NPT
18
5
93290
TEE MXFXF BLACK IRON 1/4" NPT
19
3
123536
BUSHING: REDUCING 1/4" X 1/8" NPT
20
1
61002-17
HIGH GAS PRESSURE SWITCH 10.5" W.C.
21
1
63125
HARNESS: GAS TRAIN 7 SEC IGNITION
22
1
61002-18
LOW GAS PRESSURE SWITCH 8.5" W.C.
23
3
99014
NIPPLE: HEX 1/4" NPT X 3/8" NPT
24
1
99015
DAMPING ORIFICE: SSOV
25
1
122403
SWITCH: LOW -6.90" W.C.
26
1
124862
RESISTOR ASSY
27
4
12951-2
BUSHING: CONTROL BOX
28
1
9-43
BUSHING: REDUCING 1/2 X 1/4 NPT
29
3
92077
1/4" NPT MXF BRASS BALL VALVE (OPEN)
30
3
9-22
PIPE PLUG: 1/4" NPT: STEEL
31
1
24384
MAXITROL REGULATOR W/ 2-6" SPRING
32
2
12609-3-2
3/8" X 1/4" HEX RED. BUSHING
33
1
124866
SOLENOID VALVE: 1/4" NPT
34
2
124089
NIPPLE: 1/4" NPT X 3" SCH.40: C.S.
35
1
123254
NIPPLE: 1/4" NPT X 1.50 LG
36
1
124084
ELBOW: 1/4" NPT 150# M/I
37
1
63131-1
PIG TAIL: 4"
38
1
63131-2
PIG TAIL: 4"
39
3
63108
SSOV/RELAY JUMPER
40
1
63043
HARNESS: WIRING: IRI
41
1
124149-3
WIRE ASSY: JUMPER O.T. SWITCHES
42
1
97005-5
TUBING: FLEXIBLE GAS 18"
X
1
64089
MAXITROL 325-3 PRESSURE REGULATOR
X
1
59205
MAXITROL REGULATOR SPRING
X
1
59204
SIEMENS SETPOINT SPRING 15-120
X
1
69005
ACTUATOR: SSOV W/ REGULATOR
AERCO
International, Inc.
Blauvelt, NY 10913
Benchmark 6000 FM Gas Train
07/09/2013
22172-1 rev C (AP-A-912)
Sheet 2 of 2
