Benchmark 6000 Boiler Installation, Operation & Maintenance Manual
CHAPTER 2 – INSTALLATION
OMM-0086_0D AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 Page 17 of 210
GF-133
Ph.: 800-526-0288
03/20/14
IMPORTANT
Ensure that adequate clearance exists at the rear of the unit to permit
installation and service maintenance of the AERCO Condensate Trap. Refer
to section 2.7 for Condensate Trap installation details.
When using the AERCO Condensate Neutralizer Tank for condensate
drainage, the tank must be installed in a pit, OR the boiler and AERCO
Condensate Trap must be elevated higher than 4” above the floor. See
Condensate Neutralizer Tank Instructions TID-0074 for details.
Figure 2-2: Benchmark Boiler Model 6000 Clearances
Housekeeping pad
should not extend
under the condensate
assembly
4” – 8”
4” MINIMUM
