Benchmark 1500 - 2000 Boilers
APPENDIX H – PART DRAWINGS
Page 156 of 188 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 OMM-0097_0D
Ph.: 800-526-0288
GF-142
TABLE A – Benchmark 1500 TABLE A – Benchmark 2000
Part No. Description Item 88 Item 87 Part No. Description Item 88 Item 87
58088-C30 30 PSI KIT (CONBRACO) 92023-1 69087-2 58087-1 30 PSI 123260-W30 69087-2
58088-C50 50 PSI KIT (CONBRACO) 92023-2 69087-2 58087-2 50 PSI 123260-W50 69087-2
58088-C60 60 PSI KIT (CONBRACO) 92023-3 69087-3 58087-3 75 PSI 123260-W75 69087-3
58088-C75 75 PSI KIT (CONBRACO) 92023-4 69087-3 58087-4 100 PSI 123260-W100 69087-3
58088-C100 100 PSI KIT (CONBRACO) 92023-5 69087-3 58087-5 150 PSI 123260-W150 69087-4
58088-C125 125 PSI KIT (CONBRACO) 92023-6 69087-3 58087-6 60 PSI 123260-W60 69087-3
58088-C150 150 PSI KIT (CONBRACO) 92023-7 69087-4 58087-7 125 PSI 123260-W125 69087-3
58088-W30 30 PSI KIT (WATTS) 92023-8 69087-2 58087-8 160 PSI 123260-K160 69087-4
58088-W50 50 PSI KIT (WATTS) 92023-9 69087-2
58088-W60 60 PSI KIT (WATTS) 92023-10 69087-3
58088-W75 75 PSI KIT (WATTS) 92023-11 69087-3
58088-W100 100 PSI KIT (WATTS) 92023-12 69087-3
58088-W125 125 PSI KIT (WATTS) 92023-13 69087-3
58088-W150 150 PSI KIT (WATTS) 92023-14 69087-4
58088-W160 160 PSI KIT (KUNKLE) 92023-15 69087-4
Benchmark 1500-2000 Kits Available
Part # Description
24311-4 AIR/FUEL VALVE KIT – BMK 2000
24311-3 AIR/FUEL VALVE KIT – BMK 1500
24356-1 FLAME DETECTOR KIT
58023 IGNITOR-INJECTOR REPLACEMENT KIT
Benchmark 1500 - 2000 Part List – Continued
Item # Qty Part # Description Item # Qty Part # Description
SHEET METAL/PANEL ASSEMBLY OTHER ACCESSORIES & PARTS
72 1 37117 BACK PANEL: LEFT 87  1
SEE
TABLE A
PRESSURE/TEMP GAUGE
73  1 37118 BACK PANEL RIGHT 88  1
SEE
TABLE A
PRESSSURE RELIEF VALVE
74 2 35029 TOP RAIL 89  1 123540 EXT. MANUAL SHUT-OFF VALVE
75 1 25078 ASSEMBLY: FRONT PANEL 90 1 69126 LOW WATER CUTOFF/CAPACITOR ASSY
76 1 25072 FRONT PANEL ASSY 91 1 123863 1/8" NTP BALL VALVE
77 1 72068 DOME LABEL 92 1 92094 3/4" DRAIN VALVE
78 2 59179 HANDLE, CONCEALED 93  1 59043 CONDENSATE FLOAT
79 4 59133 LATCH 94  1 24060 COND. TRAP ASSY
80 1 37119 FRONT TOP PANEL 95 1 59178 1/8" AIR VENT
81 1 37120 BACK TOP PANEL 96 1 90052 NIPPLE 1/8" X 1.50 LG
82 2 30117 SIDE PANEL 97 1 24386 I/O- POWER BOX ASSY, 110 V
83
1 74031 BMK 1500 LOGO
1 74033
BMK 2000 LOGO
100  1 92084-6
MOTORIZED SEQUENCING VALVE
(OPTIONAL)
84 1 39164 AIR INLET ADAPTER
 Not shown on drawing
AERCO
International, Inc.
Blauvelt, NY 10913
Benchmark 1500-2000 Part List 02/01/2014
Whole Boiler 29313-1 – 29337-1 Sheet 2 of 7
