AERCO BMK 1500-2000 User Manual
Page 110
Benchmark 1500 - 2000 Boilers
CHAPTER 8 – TROUBLESHOOTING GUIDE
Page 110 of 188
AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913
OMM-0097_0D
Ph.: 800-526-0288
GF-142
Figure 8-1: Igniter-Injector & Flame Detector Mounting Details
Figure 8-2: SSOV Actuator with Gas Pressure Adjustment
BRASS HEX HEAD
(Remove to access
the Gas Pressure
Adjustment Screw).
DAMPING ORIFICE
STAGED
IGNITION
SOLENOID
FLAME
DETECTOR &
GASKET
FLAME
OBSER-
VATION
PORT
INJECTOR-
IGNITOR
ASSY WITH
INDEXING
(CLOCKING)
WASHERS
(0-3 as
needed)
O2 SENSOR
& WASHER
BURNER PLATE
FLANGE
BLOWER
PLENUM
