KEYENCE SR-700 Series - Manual

1 E SR-700-IM
ULTRA-COMPACT Code Reader
SR-700 Series
Instruction manual
Read this instruction manual before using the product in order to achieve
maximum performance.
Keep this instruction manual in a safe place after reading it so that it can be
used at any time.
„ Symbols
The following symbols alert you to important messages. Be sure to read
these messages carefully.
Important
It indicates cautions and limitations that must be followed during operation.
Point
It indicates additional information on proper operation.
Reference
It indicates tips for better understanding or useful information.
indicates the reference pages in this manual or the reference pages in separate manuals.
Safety Information for SR-700 Series
„ General Precautions
Safety precautions on Laser product
The SR-700 Series ULTRA-COMPACT Code Reader uses a visible
semiconductor laser, with a wavelength of 660 nm, as a Laser pointer for
adjusting the reading position.
„ Laser Pointer Specifications
* The laser classification for FDA(CDRH) is implemented based on
IEC60825-1 in accordance with the requirements of Laser Notice No.50.
Follow the instructions mentioned in this manual. Otherwise, injury to the
human body (eyes and skin) may result.
Precautions on Proper Use
Precautions on Regulations and Standards
„ CE Marking
Keyence Corporation has confirmed that this product complies with the
essential requirements of the applicable EC Directive, based on the
following specifications. Be sure to consider the following specifications
when using this product in the Member State of European Union.
z EMC Directive (2004/108/EC)
• Applicable standards EMI : EN61326-1, Class A
EMS : EN61326-1
• This product is intended to be used in an industrial electromagnetic
environment.
Remarks:
These specifications do not give any guarantee that the end-product with
this product incorporated complies with the essential requirements of
EMC Directive. The manufacturer of the end-product is solely responsible
for the compliance on the end-product itself according to EMC Directive.
z Low-voltage Directive (2006/95/EC)
• Applicable Standard EN60825-1,
Class 1 Laser Product
EN62471
„ CSA Certificate
This product complies with the following CSA and UL standards and has
been certified by CSA.
• Applicable standards: CAN/CSA C22.2 No.61010-1
UL61010-1
Be sure to consider the following specifications when using this product as a
product certified by CSA.
• Overvoltage category
• Use this product under pollution degree 2.
• Use this product at the altitude of 2000 m or less.
• Indoor use only.
• When using this product, use the following power supply.
•CSA or UL certified power supply that provides Class 2 output as defined
in the CEC (Canadian Electrical Code) and NFPA79 (NEC: National
Electrical Code), or
•CSA or UL certified power supply that has been evaluated as a Limited
Power Source as defined in CAN/CSA-C22.2 No. 60950-1/UL60950-1.
It indicates a hazardous situation which, if not avoided, will result in death or
serious injury.
It indicates a hazardous situation which, if not avoided, could result in death
or serious injury.
It indicates a hazardous situation which, if not avoided, could result in minor
or moderate injury.
It indicates a situation which, if not avoided, could result in product damage
as well as property damage.
• Do not use this product for the purpose to protect a human body or a part
of human body.
• This product is not intended for use as explosion-proof product. Do not
use this product in a hazardous location and/or potentially explosive
atmosphere.
• Be sure to check that the SR-700 Series performs properly before starting
the work or operation.
• If the SR-700 Series malfunctions, take adequate safety precautions to
prevent various types of damage.
• Do not use the SR-700 Series in a manner not specified herein. It may
result in fire, electric shock or malfunction.
• It should be noted that functions and performances will not be guaranteed
if the SR-700 Series is used in any way not specified or described in the
product specifications or it is modified.
• When the SR-700 Series is used in combination with other devices,
functions and performance may be degraded, depending on the operating
conditions and environment.
• If the equipment is used in a manner not specified by the manufacturer.
the protection provided by the equipment may be impaired.
Wavelength 660 nm
Output 60 μW
Pulse duration 20 0μs
Laser class
Class 1 Laser Product
(IEC60825-1:2007, FDA(CDRH) Part 1040.10*)
• Use of controls or adjustments or performance of procedures other than
those specified herein may result in hazardous radiation exposure.
• Do not disassemble this product. The laser radiation emission from this
product is not automatically stopped when it is disassembled.
Precautions on Class 1 Laser Product
• Do not stare into the direct or specularly reflected beam.
96M13107
DANGER
WARNING
CAUTION
NOTICE
WARNING
CAUTION
NOTICE
WARNING
• Do not use a voltage other than 5VDC with the SR-700 Series. Doing so
may lead to damage on the unit.
• When using the dedicated communication units (N-R2/R4/UB/L1, or DV-90
Series), use a power supply within the appropriate range for each unit.
• Be sure to turn the power off to devices attached to the SR-700 Series
when you plug or unplug the cables. Failure to do so may cause damage
to the SR-700 Series.
• Do not disassemble or modify the SR-700 Series. Doing so may lead to
damage on the unit.
• Keep the cables away from high-tension cables or power sources.
Otherwise, noise could cause malfunctions or accidents.
• The SR-700 Series is a precision instrument.
Do not apply shock to the instrument or drop
it. Be especially careful when transporting or
installing the unit.
• Do not hold the SR eries by its cable. The
units may become damaged if they strike
each other.
• Do not allow water, oil, dust, or other foreign substances to stick to the
scanner. This may cause read errors. Use a soft, dry cloth to wipe any
substances from the scanner. (Do not use a cloth dipped in alcohol or
other cleaning substance.)
NOTICE
