3-6 DP-V1 Service
3-33 - PROFIBUS DP Compatible Network Unit DL-PD1 User's Manual (GT2) -
Ex
ec
ut
in
g C
om
m
uni
ca
tion
3
154 Batch setting (GT2-100* only) *14 DINT R/W 0
0: Individual
1: Batch
155 Analog Range setting *15 DINT R/W 0
0: Default
1: Free range setting
156 Free range setting (Hi) *15 DINT R/W +012.0000 -199.9999 to +199.9999
157 Free range setting (Lo) *15 DINT R/W 000.0000 -199.9999 to +199.9999
158 to
159
Reserved for system
160 Group5 Entry count DINT R 15
161 R.V. (base of calc.) ID01
*3
*16
DINT R
162 R.V. (base of calc.) ID02
*3
*16
DINT R
163 R.V. (base of calc.) ID03
*3
*16
DINT R
164 R.V. (base of calc.) ID04
*3
*16
DINT R
165 R.V. (base of calc.) ID05
*3
*16
DINT R
166 R.V. (base of calc.) ID06
*3
*16
DINT R
167 R.V. (base of calc.) ID07
*3
*16
DINT R
168 R.V. (base of calc.) ID08
*3
*16
DINT R
169 R.V. (base of calc.) ID09
*3
*16
DINT R
170 R.V. (base of calc.) ID10
*3
*16
DINT R
171 R.V. (base of calc.) ID11
*3
*16
DINT R
172 R.V. (base of calc.) ID12
*3
*16
DINT R
173 R.V. (base of calc.) ID13
*3
*16
DINT R
174 R.V. (base of calc.) ID14
*3
*16
DINT R
175 R.V. (base of calc.) ID15
*3
*16
DINT R
176 to
191
Reserved for system
192 Group6 Entry count DINT R 11
193 Product code DINT R
GT2-7* main unit:=4006
GT2-7* expansion unit:=4007
GT2-71MC:=4008
GT2-100* main unit:=4010
GT2-100* expansion unit:=4011
194 to
199
Reserved for system
200 Product name 1 *17
DINT/
STRING
R
GT2-7* main unit:="GT2-"
GT2-7* expansion unit:="GT2-"
GT2-71MC:="GT2-"
GT2-100*:="GT2-"
Index
(DEC)
Function name Description
Data
type
Attribute
Default
value
Value
