Page 55

3-6
DP-V1 Service
3-31
- PROFIBUS DP Compatible Network Unit DL-PD1 User's Manual (GT2) -
Execu
ting Communi
cat
ion
3
77
Bank 2 preset value
DINT
R/W
+001.0000
-199.9999 to +199.9999
78
Bank 2 HH setting
*8
DINT
R/W
-001.0000
-199.9999 to +199.9999
79
Bank 2 LL setting
*8
DINT
R/W
000.0000
-199.9999 to +199.9999
80
Bank 3 HIGH setting
DINT
R/W
+007.0000
-199.9999 to +199.9999
81
Bank 3 LOW setting
DINT
R/W
+005.0000
-199.9999 to +199.9999
82
Bank 3 preset value
DINT
R/W
+001.0000
-199.9999 to +199.9999
83
Bank 3 HH setting
*8
DINT
R/W
-001.0000
-199.9999 to +199.9999
84
Bank 3 LL setting
*8
DINT
R/W
000.0000
-199.9999 to +199.9999
85 to 95 Reserved for system
96
Group3 Entry Count
DINT
R
7
97
Key lock
*9
DINT
R/W
0
0: Unlock
1: Full key lock
2: Key lock
98
Bank switching state
*10
DINT
R
0
0 to 3: Currently active bank
W
0
0: Switched to bank 0
1: Switched to bank 1
2: Switched to bank 2
3: Switched to bank 3
99
Timing status
DINT
R
0
0: Timing input OFF, or in
process of measurement
using self-timing
1: Timing input ON, or not in
process of measurement
using self-timing
W
0
0: Change during measurement
1
: Change during non-measurement
100 to
102
Reserved for system
103
Bar display mode
*11
DINT
R/W
0
0: Bar display mode
1: OK/NG display mode
104 to
127
Reserved for system
128
Group4 Entry count
DINT
R
29
129
Calculation mode and Setting
*12
*13
DINT
R/W
0
00+m: Does not use the
calculation function
10+m: Use the calculation
function
20+m: Calculation only mode
0:
Maximum value
1:
Minimum value
2:
Flatness
3:
Average
4:
Reference difference
5:
Twist
6:
Warpage
7:
Thickness
130
Detection mode
DINT
R/W
0
0: Standard
1: NG hold
2: Peak hold
3: Bottom hold
4: Peak-to-Peak
131
Hold update method
DINT
R/W
0
0: Timing
1: Regular update
Index
(DEC)
Function name
Description
Data
type
Attribute
Default
value
Value
