1-1 Characteristics of the DL-PD1
1-3 - PROFIBUS DP Compatible Network Unit DL-PD1 User's Manual (GT2) -
Be
fo
re
U
sin
g
1
Types and Number of Connectable Sensor Amplifiers
 Number of Connectable Sensor Amplifiers
* Up to 11 sensor heads can be connected by adding a head connection board to the
main unit.
The DL-PD1 can connect to multiple sensor amplifiers (a single main unit and multiple
expansion units) which support D-bus. "D-bus" is the name of KEYENCE's wiring-saving
system for sensor amplifiers.
Different types of sensor amplifiers with D-bus support can be connected to a single DL-
PD1 unit.
How many and what types of sensor amplifiers can be connected depends on the
sensor amplifiers or units to be connected. Please inquire for details.
Name Amplifier form Main unit Expansion unit Maximum number of connectable units
GT-2 Series
DIN rail mounting
type GT2-71(M)(C)N
GT2-71(M)(C)P GT2-71(M)(C)N
GT2-71(M)(C)P 15
(1 main unit, 14 expansion units)
Panel mounting type
GT2-75N
GT2-75P GT2-76N
GT2-76P 15
(1 main unit, 14 expansion units)
Large display type
GT2-100N
GT2-100P
-
1
(1 main unit)*
