3-6 DP-V1 Service
3-30 - PROFIBUS DP Compatible Network Unit DL-PD1 User's Manual (GT2) -
Execu
ting Communi
cat
ion
3
GT2 series index (Slot 1 to 15)
Attribute R: Read; W: Write; R/W: Read/Write; C: Motion command
The data types are DINT (32-bit signed integer).
Index
(DEC)
Function name Description
Data
type
Attribute
Default
value
Value
0 Group0 Entry count DINT R 5
1 Preset request DINT C
2 Preset reset request DINT C
3 Reset request DINT C
4 Error clear DINT C
5 Initialize request DINT C
6 to 31 Reserved for system
32 Group1 Entry Count DINT R 9
33 Sensor amplifier error state *1 DINT R
Bit0: Overcurrent error (ErC)
Bit1: Head error (ErH)
Bit2: EEPROM error (ErE)
Bit3: Jam check error (Er.chK)
Bit4: Self-timing delay error
(Er.dLY)
Bit5: Number-of-units error
(Er.Unit)
Bit6: Calculation error (Er.CAL)
Bit7: Calculation mode error
(Er.noH)
34 to 35 Reserved for system
36 Control output *2 DINT R
Bit0: HIGH
Bit1: LOW
Bit2: GO
Bit3: HH
Bit4: LL
37 Comparator value (P.V. value)
*3
*4
DINT R
38 Raw value (R.V. value)
*3
*5
DINT R
39 Peak value during sampling *3
*6 DINT R
40 Bottom value during sampling DINT R
41 Calculation display value
*3
*7
DINT R
42 to 63 Reserved for system
64 Group2 Entry count DINT R 20
65 Bank 0 HIGH setting DINT R/W +005.0000 -199.9999 to +199.9999
66 Bank 0 LOW setting DINT R/W +001.0000 -199.9999 to +199.9999
67 Bank 0 preset value DINT R/W 000.0000 -199.9999 to +199.9999
68 Bank 0 HH setting *8 DINT R/W +007.0000 -199.9999 to +199.9999
69 Bank 0 LL setting *8 DINT R/W -001.0000 -199.9999 to +199.9999
70 Bank 1 HIGH setting DINT R/W +007.0000 -199.9999 to +199.9999
71 Bank 1 LOW setting DINT R/W +005.0000 -199.9999 to +199.9999
72 Bank 1 preset value DINT R/W +001.0000 -199.9999 to +199.9999
73 Bank 1 HH setting *8 DINT R/W -001.0000 -199.9999 to +199.9999
74 Bank 1 LL setting *8 DINT R/W 000.0000 -199.9999 to +199.9999
75 Bank 2 HIGH setting DINT R/W +007.0000 -199.9999 to +199.9999
76 Bank 2 LOW setting DINT R/W +005.0000 -199.9999 to +199.9999
