- EtherNet/IP Compatible Network Unit DL-EP1 User’s Manual (SK-1000) -
3-4 Message Communication
3-44
3
Commu
nic
ati
ng
wi
th t
he SK-1000
S
eries
*1
The on/off status of the bits indicates the type of error occurred in the sensor
amplifier.
OFF (0): No error, ON (1): Error occurred
More than one error may occur simultaneously. For details of the errors, refer to
“SK-1000 Series Instruction Manual”.
*2
This is -999.8 when the temperature is not acquired correctly.
*3
This is 999.8 when the humidity is not acquired correctly.
*4
If a prohibited combination of functions is written, an "abnormal setting (1)" will
result. For details on each function, see the "SK-1000 Series Instruction
Manual."
*5
The results of the "Initial reset request" and "System parameter set request"
operation commands are also included in this item.
*6
The result of "Zero shift execution request" or "Zero shift reset execution
request", whichever requested last, will be read.
*7
By reading "Current system parameters", you can check the system
parameters of the sensor amplifier. The system parameters refer to the polarity
of the judgment and alarm outputs and the analog output setting. Specify the
system parameters to be set when "System parameter set request" is executed
in an operation command.
Group6
03C4H
(964) to
03C7H
(967)
(Reserved for system)
03C8H
(968)
Product name
Indicates the product name.
Main unit
: "SK-1000"
Expansion unit : "SK-1050"
R
STRING
03C9H
(969) to
03D6H
(982)
(Reserved for system)
03D7H
(983)
Series code
Indicates the series code.
Main unit
: 4024
Expansion unit : 4025
R
DINT
03D8H
(984)
Series version
Indicates the series version.
Parameter range: 1
R
DINT
03D9H
(985)
Device type
Indicates the device type.
Parameter range: 0
R
DINT
03DCH
(988) to
03DFH
(991)
(Reserved for system)
Class
Attribute
ID
Name
Description
Attribute
Data
Type
