KEYENCE DL-EP1 - Manual (Page 70)

- EtherNet/IP Compatible Network Unit DL-EP1 User’s Manual (SK-1000) -
3-4 Message Communication
3-42
3
Commu
nic
ati
ng
wi
th t
he SK-1000
S
eries
Group4
0389H
(905)
(Reserved for system)
038AH
(906)
Timing input
setting
Set up timing input.
Parameter range: 0 to 1 (initial value: 0)
0:Level
1:Edge
R/W DINT
038BH
(907) to
038CH
(908)
(Reserved for system)
038DH
(909)
Hysteresis
Set up hysteresis.
Parameter range: 0.000 to 99.999
(initial value: 0.100)
R/W DINT
038EH
(910)
Analog output
scaling *9
Set the analog output scaling.
(For main unit only.)
Parameter range: 0 to 1 (initial value: 0)
0: Initial state
1: Free range
R/W DINT
038FH
(911)
Analog output
upper limit *9
Set the analog output upper limit.
(For main unit only.)
Parameter range: -99.999 to 99.999
(initial value: +10.000)
R/W DINT
0390H
(912)
Analog output
lower limit *9
Set the analog output lower limit.
(For main unit only.)
Parameter range: -99.999 to 99.999
(initial value: -10.000)
R/W DINT
0391H
(913)
External input
*10
Set up whether to change the function
assigned to external input 1/2/3/4 from the
initial state.
Parameter range: 0 to 1 (initial value: 0)
0:Initial state
1:User setting
R/W DINT
0392H
(914)
External input 1
*10
Set up function to be assigned to external
input 1.
Parameter range: 0 to 3 (initial value: 0)
0:Zero shift input
1:Bank A input
2:Bank B input
3:Not used
R/W DINT
0393H
(915)
External input 2
*10
Set up function to be assigned to external
input 2.
Parameter range: 0 to 3 (initial value: 0)
0:Reset input
1:Bank A input
2:Bank B input
3:Not used
R/W DINT
0394H
(916)
External input 3
*10
Set up function to be assigned to external
input 3.
Parameter range: 0 to 3 (initial value: 0)
0:Timing input
1:Bank A input
2:Bank B input
3:Not used
R/W DINT
0395H
(917)
External input 4
*10
Set up function to be assigned to external
input 4.
Parameter range: 0 to 2 (initial value: 0)
0:Bank A input
1:Bank B input
2:Not used
R/W DINT
Class
Attribute
ID
Name Description Attribute
Data
Type
