- EtherNet/IP Compatible Network Unit DL-EP1 User’s Manual (SK-1000) -
3-3 Cyclic communication
3-16
3
Commu
nic
ati
ng
wi
th t
he SK-1000
S
eries
 Warning code list
No warning code occurs in the DL-EP1 and in the SK-1000 Series sensor amplifiers
connected to the DL-EP1.
The data to the sensor amplifier is assigned to the OUT area of the EtherNet/IP
scanner.
 External Input (5 Words (10 Bytes)) assembly instance (Instance ID): 65H
ID numbers (ID01 to ID08) are assigned for each sensor amplifier according to the
number of sensor amplifiers. The ID numbers larger than the number of connected
sensor amplifiers and ID09 to ID15 are not assigned.
* You use the external inputs by assigning specific functions. For details of the
functions to be assigned, refer to “SK-1000 Series Instruction Manual”.
Assignment to OUT Area (Scanner to DL-EP1)
DL-EP1 data
Scanner's OUT area
Address 0
Address 1
Address 9
External Input
(Assembly Instance: 101)
1-byte (8-bit) data
Name
Address
(Byte)
bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0
External
Input
Request 1
(External
Input 1)
0 ID08 . . . . . ID01
1
Reserved for
system
ID15 . . . . . ID09
External
Input
Request 2
(External
Input 2)
2 ID08 . . . . . ID01
3
Reserved for
system
ID15 . . . . . ID09
External
Input
Request 3
(External
Input 3)
4 ID08 . . . . . ID01
5
Reserved for
system
ID15 . . . . . ID09
External
Input
Request 4
(External
Input 4)
6 ID08 . . . . . ID01
7
Reserved for
system
ID15 . . . . . ID09
External
Input
Request 5
(Unassigned)
8 ID08 . . . . . ID01
9
Reserved for
system
ID15 . . . . . ID09
