KEYENCE NU/FS-N Series - Manual (Page 7)

1 FS-N Series
5 - Sensor Amplifier Network Manual -
nn: ID number of sensor amplifier
Example: If the ID number is 13, then: nn30h->1330h, and (nn x 10+3)d->133d
R: Write; W: Read; C: Motion command
InstID: Instance ID; AttrID: Attribute ID
Parameter List
CC-Link DeviceNet
Name Attribute
Data
type
Initial
value
Parameter range
Data
category
(Hex)
Data no.
(Hex)
Inst ID
AttrID
(Hex)
00
nn00
nn
64 Group0 Entry count *1 R INT 16 16
nn01 65 Load Recipe Data C
nn02 66 Custom Save C
nn03 67 Maximum Sensitivity Setting C
nn04 68 Percentage Calibration C
nn05 69 Two-point/Pos. Calibration (1st) C
nn06 6A Two-Point Calibration (2nd) C
nn07 6B Positioning Calibration (2nd) C
nn08 6C Full Auto Calibration start C
nn09 6D Full Auto Calibration end C
nn0A 6E Zero-shift start C
nn0B 6F Zero-shift end C
nn0C 70 Preset start C
nn0D 71 Preset end C
nn0E 72 Saturation Canceling start C
nn0F 73 Saturation Canceling end C
nn10 74 Reset Hold Value C
nn11 -
nn1F
75 - 83 System reserved - - - -
nn20
nn x 10 +1
64 Group1 Entry count *1 R INT 19 19
nn21 65 Error Information R WORD 0
0:No Error 1:Error
Bit 0
Ovecurrent Error
Bit 1 Always 0
Bit 2 EEPROM Error
Bit 3 Always 0
Bit 4 Always 0
Bit 5 DATUM Correction Error
Bit 6 APC Error
Bit 7 Sensor Communication Error
nn22 66 Warning Information R WORD 0
0 : No Warning
1 : Limit Output ON
nn23 67 Warning Function R WORD 0
0 : Not Active
1 : Active
nn24 68 Output R WORD 0
Bit 0 [Out1] 0: Off 1: On
Bit 1 [Out2] 0: Off 1: On
nn25 69 Current Value R INT 0 0 - 9999
nn26 6A System reserved - - - -
nn27 6B System reserved - - - -
nn28 6C Raw Value R INT 0 0 - 9999
nn29 6D Peak-Hold Value R INT 0 0 - 9999
nn2A 6E Bottom-Hold Value R INT 0 0 - 9999
nn2B 6F System reserved - - - -
nn2C 70 Peak-Hold Minimum Value R INT 0 0 - 9999
nn2D 71 DATUM Internal Value R INT 0 0 - 9999
nn2E 72 Display Customize R INT 0
0: No Customize / DATUM
1: Preset
2: Zero-shift
nn2F 73 Slide Switch Status R INT 0
0: Selecting SEL
1: Selecting MEGA
