Chapter 6 - Operating Procedures
6-7
Block Transfer, Write
WORD PARAMETER
0 Setpoint 1
Value (32 bit float, or integer)
MSW
1 Setpoint 1
Value (32 bit float, or integer)
LSW
2 Setpoint 1
Deadband (32 bit float, or integer)
MSW
3 Setpoint 1
Deadband (32 bit float, or integer)
LSW
4 Setpoint 1
Preact (32 bit float, or integer)
MSW
5 Setpoint 1
Preact (32 bit float, or integer)
LSW
6 Setpoint 1 Mode
Bit Setpoint Mode
0 ROC (Rate of Change)
1 Gross
2 Net
3 Gain Mode (0 = gain in wght)
(1 = loss in wght)
4 Force Low
5 Force High
6 Excitation Error
7 No Excitation Error
8-15 Currently Not Used
7 Setpoint 2
Value (32 bit float, or integer)
MSW
8 Setpoint 2
Value (32 bit float, or integer)
LSW
TABLE 6-2: BLOCK TRANSFER, WRITE
