HI 1746-WS WEIGH SCALE MODULE
4-4
NOTE:
After making the change, you need to save the change
to non-volatile memory.
Changes can be made one word at a time or up to 37
words (all parameters) at a time.
NOTE:
If multiple words written to the module at the same
time, data must be in the same order and have the cor-
rect length for each parameter.
The mapping is as follows for all the parameters:
Parameter
Word
Tare Weight (float)
28
Span Weight (float)
30
CalLO Weight (float)
32
Set Point 1 (float)
34
Dead Band 1 (float)
36
Preact 1 (float)
38
Set Point 2 (float)
40
Dead Band 2 (float)
42
Preact 2 (float)
44
Zero Tolerance (float)
46
Auto Zero Tolerance (float)
48
Motion Tolerance (float)
50
Parameter
Word
Metric (int)
52
Waversaver (int)
53
Averages (int)
54
Zero Track Enable (int)
55
Tare Enable (int)
56
Zero Enable (int)
57
ROC Time Base (int)
58
Setpoint 1 Type (int)
59
Setpoint 2 Type (int)
60
Cal Year (int)
61
Cal Month (int)
62
Cal Day (int)
63
Cal ID (int)
64
