PeciFicAtioNs
GPIO Specifications
The following table lists the specifications for the General Purpose
Input/Output (GPIO) terminal blocks found on Pro64 Series products.
INPUT
MODE Parameter Conditions Symbol Rating
TT
L
Input isolation to
chassis
Rin iso 1 Mohms
IS
O
LA
TE
D Use only with on/off switch‑type signals.
IS
O
LA
TE
D
/T
TL
Input Voltage Minimum VIL 2V
Maximum VIH1 17V
Bandwidth BW 200 Hz
Output Current
(Continuous)
Outputs are
overcurrent
protected with
PTCs.
IL2 330 mA
Output Current
(Peak)
PW=100 msec (1 shot) Ifp 1.5A
Output isolation to
chassis
Rout iso 1.00E+09 ohms
Output On‑State
Resistance
IL = 500 mA Ron 0.85 ‑ 2.5 ohms
Output Breakdown
Voltage
Vbr 60V
Ratings subject to change without notice.
Inputs are reverse polarity protected up to 17VDC.
