PeciFicAtioNs
Specifications
6416o
XLR Output (line level) Pin 1: Ground; Pin 2: Hot ; Pin 3: Cold ;
Impedance balanced; signal on hot only
Alternate Audio Output (2) DB25 connectors;
Analog audio pinout on DB25
Output Levels +4dBu, ‑17dBu
2‑position switch
Output Impedance 91 ohms
Frequency Response ‑3dB at 2Hz and 23kHz
± .5dB 3.0Hz–22kHz (at 1x sample rate)
6416o v.2
XLR Outputs Pin 1: Shield; Pin 2: Hot; Pin 3: Cold
Impedance balanced for Mic, +4dBu, and
+18dBu, Signal on hot only; Full differential
for +24dBu
Alt. Audio Outputs DB25 multipin; analog audio pinout
Output Impedance 200 ohms for Mic and +4dBu;
450 ohms for +18dBu and +24dBu
Output Levels +4dBu, +18dBu, +24dBu, or Mic;
4‑position switch per channel
Max. Output Level +24dBu
6416o and 6416o v.2 Common Specs
Audio Channels 16 mic or line‑level outputs
Audio Metering LEDs: Green ‑40dB; Yellow ‑10dB; Red 0dB
A-Net I/O (2) EtherCon RJ45 connectors
Sample Rates 44.1/48kHz; 88.2/96kHz; 176.4/192kHz
Sample Rate Range 1x 44.1/48kHz, 39.7kHz to 52kHz
2x 88.2/96kHz, 79.4kHz to 104kHz
4x 176.4/192kHz, 158.8kHz to 208kHz
Bit Depth 24‑bits
Latency Total latency is less than 800μs (measured
from analog in to analog out).
Cable Length, Cat-5e Maximum 400 feet (120 meters);
Use Unshielded Twisted Pair (UTP) cable
DB25 connector Thread size is #4‑40 UNC
Crosstalk <100dB at 1kHz
THD +N < .002% at ‑10dBFS
