75
s
PeciFicAtioNs
Signal to Noise Ratio
(unweighted)
D/A: ‑111dB
Maximum Ambient
Temperature
50°C
Virtual Data Cables (VDC)
GPIO
4x in; 4x out
Isolated or TTL
Inputs: 4 terminal blocks, individually
configurable as Isolated or TTL
Outputs: 4 terminal blocks
Maximum inputs to network VDC slots: 14
MIDI
In, Out
5‑pin DIN
Maximum inputs to network VDC slots: 14
RS-232
DB9 connector
DIP switch configured
RS-232
Baud
Rates
1200, 2400, 4800, 7200, 9600, 14400, 19200,
28800, 38400, 57600, 31250 (MIDI)
Maximum inputs to network VDC slots: 7
Power Supply
100‑240VAC
50‑60Hz, 24W
Internal switching power supply;
IEC connector, interchangeable
Fuse
F4AL
Dimensions
2U; 19”w x 8”d x 3.5”h
482.6 x 203 x 88 mm
Weight
9 pounds;
4.1 kg
All Aviom products are designed and manufactured in the USA.
