TCR Series UserManual Operations 4-19
Synchronizing Multiple TCRs
Connect WORD CLOCK OUT on the master TCR to WORD CLOCK IN on the slave TCRs.
Connect LTC OUT on the master TCR to LTC IN on the slave TCRs.
Select the following options on the master TCR using the Machine Setup | Sync and Time Code
menu:
LTC Level: +15 DBV BAL
Output LTC: DURING 1X PLAY ONLY
Select the following options on the slave units, using the Machine Setup | Sync and Time Code
menu:
Sync Ref: WORD CLOCK
Rate/Format: Same as master TCR
TC Input: LTC
Chase What: EXTERNAL TIME CODE
Chase When: CHASE PRESSED
Chase Until: CHASE CANCELLED
Press CHASE on the slave TCRs. When the master TCR plays, the slave units will follow
synchronously.
Note The slave machines do not track jog and shuttle operations on the
master.
