Compaq 9900 - Manual (Page 104)

90 Chapter 5 Planning for Installation and Operation
to Disk Array
to power
distribution board
R&S 3720DP
R&S 3743 or 3913
To be prepared
as apart of power facility Provided with
DKU-F405I-1UC
Rear View of
9960 Disk
Array
CB101
Front View of
9960 Disk
Array
Figure 5.10 Power Plugs for Single-Phase 9960 Disk Array Unit (USA)
G
L1
L2
Hot Line
Hot Line
200/220/230/240V
AC Power
Protection Earth to Disk Array
Brown
Blue
Provided with
DKU-F405I-1EC To be prepared
as a part of power facility
Green/Yellow
CB101
Rear View of
9960 Disk
Array
Front View of
9960 Disk
Array
Figure 5.11 Power Plugs for Single-Phase 9960 Disk Array Unit (Europe)
