Component Video Connection

Héipfüj^^

An input signal must be^connected to
the input terminals of the monitor, in

order to access PC and DTV mode

Icon menus.

Operation

1. Select DTV mode from the TV/PC/DTV menu {located in the TV/PC/DTV Icon).

2. Connect audio/video cables from the Component Video output terminals to the monitor DIGITAL TV

INPUT terminals, as shown.

: TO Operate your Monitor with component video devices properly, refer to the instructions furnished

with the component video device.

TERMINALS ON BACK OF DEVICE

TERMINALS ON BACK OF MONITOR

VIDEO

From

audioA/ideo

output of device

';® ,

®v3 “ AUDIO;

ini IН

НН

VIDEO

íc

audioArideo

input of monitor

audio/video Cable

(not supplied)
