Table of Contents (cont’d.)
DTV MODE
Components Video Connection ......................... 44
TV/PC/DTV .................................................................. 45
Trilingual Animated Icons..........................................45
DTV Mode Icons.............................................. 45
Picture Adjustments ..................................................45
Picture Norm....................................................45
Color, Tint, Brightness, Picture and
Sharpness Adjustments................................45
Color Temp ..................................................... 46
Audio Adjustments ................................................... 46
Audio Norm...................................................... 46
Bass, Treble and Balance................................46
Speaker .......................................................... 47
Surround ..........................................................47
Al Sound .......................................................... 47
Set Up Features .......................................................... 48
Auto Power On................................................. 48
Aspect Ratio .................................................... 48
Color Matrix...................................................... 48
Geomagnetic Corr (Correction) ....................... 48
TROUBLESHOOTING SECTION
Troubleshooting Chart ................................................. 49
Computer Resolution Set Up For Windows 95 .. 50
Computer Resolution Set Up For Windows 3.X . 51
Specifications
Power Source: 120V ac, 60Hz
Channel Capability Chart
Channel Capability: 181 channels (See chart)
VHF 2-13, UHF 14-69,
Cable 125 channels
BAND CHANNELS
VHF
UHF
12
56
Video Input Jacks (2): IV p-p, 75 ohm, phono jack type
CABLE (Mid-Band) 15
Audio Input Jacks (2): 500mV rms, 47K ohm CABLE (Super Band) 14
To Audio Amp Jacks: 0-2.0V rms 4.7K ohm CABLE (Hyper Band) 28
S-Video Input Jack (2): S-Video (Y-C) Connector
CABLE (Ultra Band) 56
DTV Input Jacks: Component Video (Y, Ffe , R )
TOTAL CHANNELS 181
Stereo Sound:
Surround Sound:
NTSC with DBX Noise Reduction
Matrix
Computer Monitor Specifications
PC and Mac Compatible
Viewable Image Size
Dot Pitch
Multi-scan Rate
Horizontal Frequency Range
Vertical Frequency Range
Max. Data Resolution
Linearity Correction
S-Curve Correction
Dynamic Astigmatism and
Focus Correction
Yes
36.0 inches
Data Grade
Yes
15 kHz to 38 kHz
50 Hz to 120 Hz
800 X 600 @ 60 Hz
Automatic
Yes
Yes
Audio Input-computer Mini-jack on front panel
Computer Input 2-Front and rear 15-pin connector
Signal Capability Chart
Signal Format Horiz. Freq. Vert. Freq.
NTSC 15.75 kHz 60 Hz Interlaced
VGA 640 X 480 31.5 kHz 70 Hz
VGA text 31.5 kHz 70 Hz
VGA 640 X 480 31.5 kHz 60 Hz
SVGA 800 X 600 37.9 kHz 60 Hz
mc2 640 X 480 35 kHz 66.6 Hz
