Digital Camcorder
Information for your safety
Power Source;
DC 7.9/7.2 V
Power Consumption:
Recording
4.2 W (PV-GS29)
4.4 W IPV-GS39/PV-GS59)
Recording Format:
Mini DV (Consumer-use Digital Video SD
Format)
Tape Used:
6.35 mm digital video tape
Recording/Playback Time:
SP: 80 min.; LP: 120 min. (with DVM80)
Video
Recording System:
Digital Component
Television System:
EIA Standard: 525 lines, 60 fields NTSC color
signal
Audio
Recording System:
PCM Digital Recording
16 bit (48 kHz/2ch), 12 bit (32 kHzMch)
Image Sensor:
1/6-inch CCD Image Sensor
Lens:
Auto iris, FI.8 to F3.9, Focal Length; 1.9-57 mm,
Macro (Full Range AF)
Filter Diameter:
30.5 mm
Zoom:
30:1 Power Zoom
Monitor:
2.5-inch LCD (PV-GS29)
2.7-inch Wide LCD (PV-GS39/PV-GS59)
Viewfinder:
Color Electronic Viewfinder
Microphone:
Stereo
Speaker:
1 round speaker 20 mm
Standard Illumination:
1,400 lx
Minimum Required Illumination:
2 lx (MagicPix Mode)
Video Output Level:
I.OVp-p, 75 n
Audio Output Level (Line):
316 mV, 600 Q
Mie Input:
Mio sensitivity -50 dB (0 dB=1 V/Pa, 1 kHz)
USB:
Card reader/writer function, USB 2.0 compliant
(Hi-Speed (PV-GS59)) (Full-Speed (PV-GS39))
No copyright protection support
Digital Interface:
DV Input/Output Jack (IEEE1394, 4-pin)
Dimensions:
Approx. 69 (H) X 82 (W) X 120 (D) mm
Approx. 2-11/16 (H) X 3-1/4 (W) X 4-3/4 (D) inch
Mass:
Approx. 0.41 kg (0.90 lbs.)
(without Battery and DV cassette)
Operating Temperature:
0 ° C t o 4 0 “C (32 “F to 104 °F)
Operating Humidity:
10 % to 80 %
Card Memory Functions
Recording Media:
SD Memory Card
(8 MB /16 MB /32 MB /64 MB / 128 MB /256 MB
/512 MB /1 GB/2 GB (Maximum))
Please confirm the latest information on the
following website.
(This Site is English only.)
Still picture recording file format:
JPEG (Design rule for Camera File system,
based on Exit 2.2 standard), DPOF
corresponding
Still Image Size:
640 X 480 pixels (VGA)
WEB Camera
Compression:
Motion JPEG
Image Size:
320 X 240 pixels (QVGA)
AC Adaptor
Information for your safety
::: Power Source:
AC 110 to 240 V. 50/60 Hz
Power Consumption:
19W
DC Output:
DC 7.9 V, 1.4 A (Camcorder Operation)
DC 8.4 V, 0.65 A (Battery Charging)
Dimensions:
61 (W) X 32 (H) X
91
(D) mm
2-6/16 (W) X 1-4/16 (H) X 3-9/16 (D) Inch
Mass:
Approx. 0.11 kg (0.24 lbs.}
Mass and dimensions are approximate values.
Specifications may change without prior notice.
