► Journals and Lists
Explanation of Contents
(1) Printout date
(2) Printout time
(3) Journal number
(4) Communication result
(5) Number of pages transmitted or
received
(6) File number
(7) Duration of communication
(8) Type of communication
(9) Remote station identification
(10) Communication date
(11) Communication Start time
(12) Diagnostic
(13) Own LOGO
(14) Own ID number
(15) Own Character ID
(16) Type of communication
(17) Destination
(18) Received remote station’s ID
(19) Resolution
01-32 (Does not always begin with 01 when printed out manually)
”OK” indicates that the communication was successful.
"BUSY” indicates that the communication has failed because of busy line.
"STOP” indicates that STOP was pressed during communication.
”M-OK” indicates that the substitute reception message in memory was not
printed out.
”P-OK” indicates that memory overflow or document misfeeding occurred while
storing the documents into memory for transmission but successfully stored
document(s) was sent
”R-OK” indicates that the Confidential Communication was successful.
”3-digit Info Code” (see page 112) Indicates that the communication has failed.
: The 3‘digit number is the number of pages successfully transmitted or
received.
When the documents are stored into memory, two 3-digit numbers wili appear.
The first 3-digit number represents the number of pages successfuiiy
transmitted. The second 3-digit number represents the total number of pages
that were attempted to be transmitted.
: 001 to 255 (If the communication is stored into memory, a file number is
assigned for each communication.)
”XMT means Transmission
”RCV” means Reception
”POL” means Polling
: Name : Recorded name in One-Touch or ABBR. Numbers or remote station’s
Character ID.
S number : Dialed telephone number
Number : Remote station’s ID number.
For service personnel only
Up to 25 characters
Up to 20 digits
Up to 16 characters
Transmission or memory transmission
If a One-Touch or ABBR was used for the transmission:
One-Touch or ABBR. No.Aelephone Number/Recorded Name
If not: Telephone number
; Character ID/ID number
: ”STD” means standard resolution
’’FINE” means fine resolution
"S-FINE” means superfine resolution
