Page 40: Click to save and exit the interface

Network Camera User’s Manual

Figure 6-7

Port Settings

2. Set the HTTP port, RTSP port and Server/SDK port of the camera.

HTTP Port: The default port number is 80, and can be changed to any port range
1024 to 65535.
RTSP Port: The default port number is 554.
HTTPS Port: The default port number is 443, and can be changed to any port
range 1024 to 65535*.
Server/SDK Port: The default SDK port number is 8000.

(*The HTTPS port is not required to be configured or forwarded to view the network camera online.)

3. Click

to save the settings.

Note:

The interface will ask for a reboot for the settings to take effect.

6.3.3 Configuring PPPoE Settings

Steps:
1. Enter the PPPoE Settings interface:

Configuration >Advanced Configuration > Network > PPPoE

Figure 6-8

PPPoE Settings

2. Check the Enable PPPoE check box to enable this feature.
3. Enter User Name, Password, and Confirm password for PPPoE access.

Note:

The User Name and Password should be assigned by your ISP.

4. Click

to save and exit the interface.

Note:

it will ask for a reboot for the settings to take effect.
