Network Camera User’s Manual 25
●User Name - Enter the user name to present to the network
●Password - Enter the password of the network
●PEAP Version - Select the PEAP version used at the access point.
●Label - Select the label used by the access point.
●EAPOL version - Select version (1 or 2) depending on the version used at the
access point
●CA Certificates - Upload a CA certificate to present to the access point for
authentication
4.2 Easy Wi-Fi Connection with WPS function
Purpose:
The setting of the wireless network connection is never easy. To avoid the
complex setting of the wireless connection you can enable the WPS function.
WPS (Wi-Fi Protected Setup) refers to the easy configuration of the encrypted
connection between the device and the wireless router. The WPS makes it easy to
add new devices to an existing network without entering long pass phrases. There are
two modes of the WPS connection, the PBC mode and the PIN mode.
Note: If you enable the WPS function, you don’t need to configure the parameters
such as the encryption type and you don’t need to know the key of the wireless
connection.
Steps:
PBC Mode:
Figure 4-7 Wi-Fi Settings - WPS
Figure 4-7 Wi-Fi Settings - WPS
PBC refers to the Push-Button-Configuration, in which the user simply has to
push a button, either an actual or virtual one (as the button on the
configuration interface of the IE browser), on both the Access Point (and a registrar
of the network) and the new wireless client device.
