Configuring EVC 9145ELB NID Software User’s Manual
EVC Configuration
121
.
Figure 10-14 EVC Record Statistics (Current) screen
Figure 10-15 EVC Record Statistics (Raw) screen
Canoga Perkins Corp. Ethernet 1G/10G Network Interface Device 29-AUG-2011
9145ELB-971-4-0 V04.01 10:55:13
-----------------------EVC RECORD STATISTICS (CURRENT)--------------------------
S-VLAN ID: 10
User Interface: USR1
Network Interface: NET1
Multiplexing type: Service Mux
C-VLAN level statistics: Disabled
Rx Frames at user port 0 Rx Frames at network port 0
Tx Frames at user port 0 Tx Frames at network port 0
Rx Bytes at user port 0 Rx Bytes at network port 0
Tx Bytes at user port 0 Tx Bytes at network port 0
Select [CTRL-T - current/raw, (R)eset counters, ESC to return]:
------------------------------------Messages-----------------------------------
Canoga Perkins Corp. Ethernet 1G/10G Network Interface Device 29-AUG-2011
9145ELB-B83-0 V04.01 01:27:03
--------------------------EVC RECORD STATISTICS (RAW)---------------------------
S-VLAN ID: 20
User Interface: USR12
Network Interface: LAG1
Multiplexing type: All-to-One
Rx Frames at User Port: 1010 Rx Frames at Network Port: 820
Tx Frames at User Port: 820 Tx Frames at Network Port: 1010
Rx Bytes at User Port: 1010 Rx Bytes at Network Port: 820
Tx Bytes at User Port: 820 Tx Bytes at Network Port: 1010
Select [CTRL-T to view current counters (R)eset counters, ESC to return]:
------------------------------------Messages-----------------------------------
