Configuring EVC 9145ELB NID Software User’s Manual
EVC Configuration
117
Figure 10-10 P-Bit Translation Table screen
14. To modify CVID to T-Tag PCP Mapping, type 11 and press Enter. The C-VLAN to T-Tag
PCP Map screen (Figure 10-11) opens.
NOTE: This screen is available only if T-Tag PCP mapping is set to C-VLAN. By default, any
VLAN in the EVC is assigned to PCP 0. If the T-Tag PCP mapping mode is changed, the config-
uration record will be reset to default values.
• To modify the mapping, type M and press Enter. You are prompted to enter a C-
VLAN ID.
• You can search for specific C-VLAN by ID number. See the Find instructions at
the bottom of your screen.
• Press Esc to return to the Modify EVC Configuration Record screen.
Canoga Perkins Corp. Ethernet 1G/10G Network Interface Device 29-AUG-2011
9145ELB-971-4-0 V04.01 10:55:13
---------------------------P-BIT TRANSLATION TABLE-----------------------------
S-VLAN ID: 100 Port: USER12
Ingress Port: User 13 User 14 User 15 User 16
Egress Port: Network Network Network Network
------- ------- ------- -------
1) Incoming P-Bit 0 translated to 0 0 0 0
2) Incoming P-Bit 1 translated to 1 1 1 1
3) Incoming P-Bit 2 translated to 2 2 2 2
4) Incoming P-Bit 3 translated to 3 3 3 3
5) Incoming P-Bit 4 translated to 4 4 4 4
6) Incoming P-Bit 5 translated to 5 5 5 5
7) Incoming P-Bit 6 translated to 6 6 6 6
8) Incoming P-Bit 7 translated to 7 7 7 7
9) P-Bit Translation Enabled? No
Select [1-9] or CTRL-T to switch direction:
------------------------------------Messages-----------------------------------
