9145ELB NID Software User’s Manual CoS Configuration
CoS Queues Configuration
94
Note that:
• All User Ports share the same PCP to queue classification.
• In C-VID mode, the default queue is the lowest priority queue (Q1).
• Queues for the Network side correspond to the specific ingress User Port, as described in
section 10.1.
• PCP and C-VID queue mappings work in the ingress direction. For Network Port queues,
configure the User Port mappings.
Figure 9-5 Tagged Packet Classifier screen (with PCP selected)
3. To map a PCP to a queue on the User Port, type 1 and press Enter. The User Port
Tagged Packet Classifier Mapping screen opens (Figure 9-6).
Use the Space bar to select a queue. Press Enter to confirm the setting. (Only a queue
that is enabled can be selected. To enable or disable a queue, see “Queues
Configuration on Network Ports” on page 101.)
Canoga Perkins Corp. Ethernet 1G/10G Network Interface Device 29-AUG-2011
9145ELB-971-4-0 V04.01 10:55:13
------------------- TAGGED PACKET CLASSIFIER CONFIGURATION ---------------------
Classification Mode
Network PCP
User EVC Specific
1) Set classifier mapping on User port
2) Set classifier mapping on Network port
Select [1-3]:
------------------------------------Messages-----------------------------------
