9145ELB NID Software User’s Manual CoS Configuration
CoS Queues Configuration
98
4. Press Esc to return to the User Port Untagged Packet Classifier Configuration screen.
Figure 9-10 User Port Untagged Packet Classifier Mapping screen (DSCP Mode)
9.3.2.3 Assured Forwarding (AF)/ Expedited Forwarding (EF)
On the User Port Untagged Packet Classifier Mapping screen (Figure 9-11) for AFEF:
1. Type the number of the AF code (or a range of numbers), E for Expedited Forwarding, or
D for Default Forwarding, and press Enter. The CoSQ setting, or the first number/value of
the range (for example, 3, if 3 - 7) is highlighted.
2. Press the Space bar to scroll through the available queues.
3. Select a queue and press Enter. If a series of codes was chosen, all of those CoSQs will
be changed.
Canoga Perkins Corp. Ethernet 1G/10G Network Interface Device 29-AUG-2011
9145ELB-971-4-0 V04.01 10:55:13
---------------- USER PORT UNTAGGED PACKET CLASSIFIER MAPPING ------------------
Mode: DSCP Mode
DSCP CoSQ DSCP CoSQ DSCP CoSQ DSCP CoSQ DSCP CoSQ DSCP CoSQ DSCP CoSQ
---- ---- ---- ---- ---- ---- ---- ---- ---- ---- ---- ---- ---- ----
0 Q1 10 Q1 20 Q1 30 Q1 40 Q2 50 Q3 60 Q3
1 Q1 11 Q1 21 Q1 31 Q1 41 Q2 51 Q3 61 Q3
2 Q1 12 Q1 22 Q1 32 Q2 42 Q2 52 Q3 62 Q3
3 Q1 13 Q1 23 Q1 33 Q2 43 Q2 53 Q3 63 Q3
4 Q1 14 Q1 24 Q1 34 Q2 44 Q2 54 Q3
5 Q1 15 Q1 25 Q1 35 Q2 45 Q2 55 Q3
6 Q1 16 Q1 26 Q1 36 Q2 46 Q2 56 Q3
7 Q1 17 Q1 27 Q1 37 Q2 47 Q2 57 Q3
8 Q1 18 Q1 28 Q1 38 Q2 48 Q3 58 Q3
9 Q1 19 Q1 29 Q1 39 Q2 49 Q3 59 Q3
Select DSCP or a Range x-y [0-63]:
------------------------------------Messages-----------------------------------
