HVAC Products CC1B7865en 01.09.2005 57/57
12. Actual settings
Parameter Display Factory
setting
Setting
Analog input 1, 2 and 3; setpoint
changeover / shift
C111
9030
Limit comparator; controller type;
setpoint 1; locking C112 0010
Unit address; decimal place / unit,
signal for out-of-range
C113
0110
Measured value range start
analog input 1
1.
SCL
0
Measured value range
analog input 1
1.
SCH
100
Measured value range
analog input 2
1.
SCL2
0
Measured value range
analog input 2
1.
SCH2
100
Lower setpoint limit
1. SPL
0
Upper setpoint limit 1. SPH
100
Actual value correction,
analog input 1
1.
OFF1
0
Actual value correction,
analog input 2
1.
OFF2
0
Actual value correction,
analog input 3
1.
OFF3
0
Filter time constant for digital filter,
analog input 1
dF1
1
Filter time constant for digital
filter, weather-dependent setpoint
shift
dF3 2. 1278
Lower working range limit
1. oLLo 2. -1999
Upper working range limit 1. oLHi 2. 9999
Bus watchdog timer
dtt 2. 30
1. Setting of the decimal place has an impact on these parameters
2.
Only with RWF40.0X2B97
12.3 Configuration level
