Page 13

background image

HVAC Products

CC1B7865en

01.09.2005

13/57

4. Electrical connections

3 analog inputs

2 binary inputs

Power supply

Serial port (optional)

Release of burner

Floating output

Limit comparator

Analog output (optional)

Power supply measuring transducer

RWF40...

7865f01e/0905

Input 1:
Actual value
for Pt100, Ni100, Pt1000,
LG-Ni1000,
thermocouples
or standard signals

Input 2:
External setpoint,
setpoint shifting
for 0...1 k resistor
or linearized
standard signals

Input 3:
Outside temperature
for Pt1000, LG-Ni1000

For potential-free
contacts

Input 1:
Operating mode changeover

Input 2:
Setpoint shifting /
changeover

Output 1:
- Relay (N.O. contact)

Output 2:
-Relay (actuating device open)

Output 3:
- Relay (actuating device closed)

Output 4:
- Relay (N.O. contact)

DC 24 V, 30 mA
(short-circuit proof)

Output 5:
Analog output
DC 0...10 V, DC 0...20 mA,
DC 4...20 mA

RS-485
MOD bus protocol

AC 110 ...240 V +10%/-10%,
48...63 Hz, max. 10 VA

4.2 Block diagram
