56/57 CC1B7865en 01.09.2005 HVAC Products
12. Actual settings
Parameter Display Value range Factory
setting
Setting
Setpoint 1 1) SP1 SPL-SPH 0
Setpoint 2 (option) 1) SP2 SPL-SPH 0
Digital setpoint shift (optional) 1) dSP SPL-SPH 0
Outside temperature (optional) TA Ö
Section 8.1
« C111 inputs»
-
Predefinition of external setpoint
1)
SP.E SPL-SPH -
1) Setting of the decimal places has an impact on these parameters
Parameter Display Value range Factory
setting
Setting
Limit value of limit comparator 1) AL -1999...+9999 digit 0
Switching differential for limit
comparator
1)
HYSt 0...999.9 digit 1
Proportional band 1) Pb.1 0.1...999.9 digit 10
Derivative time dt 0...9999 s 80
Integral action time rt 0...9999 s 350
Dead band (neutral zone) 1) db 0...999.9 digit 1
Actuator running time tt 10...3000 s 15 s
Switch-on threshold burner /
stage II
1)
H Y S 1 0...-199.9 digit -5
Switch-off level stage II
1) H Y S 2 0... HYS3 digit 3
Upper switch-off threshold
1) H Y S 3 0...999.9 digit 5
Response threshold q 0...999.9 0
Heating curve slope H 0...4 1
Parallel displacement 1). P -90...+90 0
1) Setting of the decimal place has an impact on these parameters
12.1 Process data
12.2 Parameter level
